Accurate measurement of mouse eye aberration combined with optical mask modulation

doi: 10.37188/CO.2023-0051
Funds:  Supported by National Key Research and Development Program of China (No. 2021YFF0700700); National Natural Science Foundation of China (No. 62075235); Youth Innovation Promotion Association, CAS(No. 2019320); Strategic Priority Research Program of the Chinese Academy of Sciences (No. XDA16021304)
More Information
  • Corresponding author: heyi@sibet.ac.cn
  • Received Date: 27 Mar 2023
  • Rev Recd Date: 19 Apr 2023
  • Accepted Date: 31 May 2023
  • Available Online: 07 Jun 2023
  • In order to solve the problem of aberration detection failure caused by double-layer reflected light of the fundus retina in standard animal model mouse during wavefront detection, a mouse eye aberration measurement technique combined with optical mask modulation was proposed to improve the accuracy of wavefront aberration measurement. First, according to the key parameters of mouse retina, we established the optical system model of mouse eye wavefront aberration detection and performed optical simulations. Then, the effects of optical masks with different apertures on the reflection beam of the non-target layer of the retina were analyzed and compared, and then the parameters of the optical mask and the experimental plan were determined. Finally, the wave front aberration detection system of the mouse eye was established, and the wavefront aberration of the mouse eye was measured in vivo. The experimental results show that the optical mask with 0.5 mm aperture can reduce the root mean square error of mouse eye wavefront aberration measurement by 74.9%, which is similar to the shielding effect of non-target layer reflected in 80% of the theoretical simulation. It can effectively block the reflected light from the non-target layer of the mouse retina, improve the detection accuracy of the wavefront aberration of the mouse eye, and lay a foundation for the further realization of high-resolution imaging of the mouse eye.
