摘要: 为满足大功率激光发射的要求，提出研制一种基于卡塞格林系统的大口径激光发射的复合式无遮拦激光扩束器，消除卡塞格林系统中心遮拦，提高激光发射效率。依据卡塞格林系统原理及其结构特征，结合伽利略折射式扩束器的特点，设计一种发射口径为550 mm的复合式无遮拦激光扩束器，采用反射式扩束器和折射式扩束器结合的方式，在卡塞格林次镜中心开通孔，使中心被遮拦激光透过。后接伽利略式折射扩束器，对中心透过光束进行扩束，两光束共轴发射。对设计的新型复合扩束器进行激光透过率实验，实验结果表明，对于波长10.6 μm激光，透过率大于95.21%，比传统卡塞格林扩束器提高22.12%。Abstract: In order to meet the requirements of high-power laser emission, a large-diameter composite laser beam expander without central obscuration based on Cassegrain system is proposed to eliminate the central obscuration of the Cassegrain system and improve the laser emission efficiency. Based on the principle of the Cassegrain system and its structural characteristics, combined with the characteristics of the Galileo refraction type beam expander, a composite laser beam expander without central obscuration with an emission aperture of 550 mm is designed. Using a combination of a reflective beam expander and a refractive beam expander, a through hole is opened in the center of the Cassegrain secondary mirror so that the center is passed through the obscured laser. The rear side is connected to a Galileo-type refracting beam expander, which expands the beam transmitted through the center, and the two beams are emitted coaxially. The laser transmittance test is carried out on a new type of composite beam expander. The experimental results show that for the laser of 10.6 μm wavelength, the transmittance is more than 95.21%, which is 22.12% higher than that of the traditional Cassegrain beam expander.
-
Key words:
- emission efficiency /
- laser beam expander /
- Cassegrain
-
表 1 反射扩束镜片尺寸参数(单位:mm)
Table 1. Lens parameters of reflective beam expander(Unit:mm)
主镜 次镜 直径 620 150 通光口径 600 140 中心孔径 140 37 近轴曲率半径 1 500 300 材料 Zerodur Si
下载: 导出CSV
表 2 折射扩束镜片参数
Table 2. Lens parameters of refractive beam expander
序号 注释 曲面类型 半径/mm 厚度/mm 材料 模式 通光口径/mm 1(STO) Sphere 223.8 12 ZNSE_SPECIAL Refract 140 2 Sphere 500 200.65 Refract 140 3 Sphere -118.3 10 ZNSE_SPECIAL Refract 36 4 Sphere 627.5 50 Refract 36 IMAGE Sphere INFINITY 0 9 756.037
下载: 导出CSV
表 3 能量测量结果(单位:J)
Table 3. Result of enegy measurement(Unit:J)
测量次数 无遮拦W2 有遮拦W1 激光器出口能量W 1 7.0 5.6 21.8 2 7.1 5.2 20.9 3 6.6 5.9 21.3 4 6.9 5.0 21.5 5 7.2 4.9 20.8 6 7.0 5.5 21.7
下载: 导出CSV
-
[1] 贾勇. 激光扩束系统的结构失调分析、优化和变倍技术研究[D]. 长春: 中国科学院研究生院(长春光学精密机械与物理研究所), 2014.JIA Y. Research on the Structural Misalignment, Optimization, and Zoom Technology of Laser Beam Expanders[D]. Changchun: Graduate University of Chinese Academy of Sciences(Changchun Inst. of Optics, Fine Mechanics and Physics), 2014. (in Chinese) [2] 孙敬伟, 吕天宇, 姚力双, 等.发射望远镜的设计与装调[J].光学 精密工程, 2014, 22(2):370-371. https://wuxizazhi.cnki.net/qikan-GXJM201402018.htmlSUN J W, LV T Y, YAO L SH, et al.. Design and assembly of transmitter-telescop[J]. Opt. Precision Eng., 2014, 22(2):370-371.(in Chinese) https://wuxizazhi.cnki.net/qikan-GXJM201402018.html [3] 刘龙飞, 佟首峰, 王超.经卡式光学天线发射的高斯光束衍射特性的研究[J].长春理工大学学报(自然科学版), 2015, 38(1):11-12. doi: 10.3969/j.issn.1672-9870.2015.01.003LIU L F, TONG SH F, WANG CH. The study of diffraction characteristics of gaussian beam transmitted by cassegrain optical antenna in laser communication[J]. Journal of Chang chun University of Science and Technology(Natural Science Edition), 2015, 38(1):11-12.(in Chinese) doi: 10.3969/j.issn.1672-9870.2015.01.003 [4] 巩盾, 王红, 田铁印.多种应用于高功率激光技术的光学系统设计[J].红外与激光工程, 2013, S1:118-122. http://mall.cnki.net/magazine/Article/JGDJ200103013.htmGONG D, WANG H, TIAN T Y. Optical design of various optical systems applied in high power laser technology[J]. Infrared and Laser Engineering, 2013, S1:118-122.(in Chinese) http://mall.cnki.net/magazine/Article/JGDJ200103013.htm [5] 齐光, 王书新, 李景林.空间遥感器高体份SiC/Al复合材料反射镜组件设计[J].中国光学, 2015(1):99-106. http://www.chineseoptics.net.cn/CN/abstract/abstract9249.shtmlQI G, WANG SH X, LI J L. Design of high volume fraction SiC/Al composite mirror in space remote sensor[J]. Chinese Optics, 2015(1):99-106.(in Chinese) http://www.chineseoptics.net.cn/CN/abstract/abstract9249.shtml [6] 孔祥蕾, 郝沛明.消除中心遮拦的反射式激光扩束新方案[J].量子电子学报, 2002, 19(3):206-208. https://www.cnki.com.cn/qikan-LDXU200203002.htmlKONG X L, HAO P M. New scheme of eliminating the central mask of reflective laser beam expander[J]. Chinese J. Quantum Electronics, 2002, 19(3):206-208.(in Chinese) https://www.cnki.com.cn/qikan-LDXU200203002.html [7] 何秉高, 安志勇, 高瑀含.扩束系统设计与分析(英文)[J].红外与激光工程, 2014, 11:3825-3831. doi: 10.3969/j.issn.1007-2276.2014.11.055HE B G, AN ZH Y, GAO Y H. Design and analysis of beam expanding system[J]. Infrared and Laser Engineering, 2014, 11:3825-3831.(in Chinese) doi: 10.3969/j.issn.1007-2276.2014.11.055 [8] 张丽琴.新型激光扩束器的设计[J].舰船科学技术, 1994, 1:47-49. http://mall.cnki.net/magazine/article/JCKX199401008.htmZHANG L Q. Design of new laser beam expander[J]. Ship Science and Technology, 1994, 1:47-49.(in Chinese) http://mall.cnki.net/magazine/article/JCKX199401008.htm [9] 史广维, 张新, 张建萍.无遮拦折反射红外光学系统[J].光学 精密工程, 2014, 22(8):1996-2000. http://www.eope.net/gxjmgc/CN/abstract/abstract15347.shtmlSHI G W, ZHANG X, ZHANG J P. Unobscured catadioptric infrared optical systems[J]. Opt. Precision Eng., 2014, 22(8):1996-2000.(in Chinese) http://www.eope.net/gxjmgc/CN/abstract/abstract15347.shtml [10] 周炳琨.高以智, 等.激光原理[M].北京:国防工业出版社2004:70-71.ZHOU B K, GAO Y ZH, et al.. Laser Theory[M]. Beijing:National Defend Industry Press, 2004:70-71.(in Chinese) [11] 虞林瑶, 魏群, 张鑫, 等.一体式紧凑型折反光学系统设计[J].光学 精密工程, 2013, 21(3):561-565. http://www.cqvip.com/QK/92835A/201303/45245243.htmlYU L Y, WEI Q, ZHANG X, et al.. Design of compact integral structure of two-, mirror system[J]. Opt. Precision Eng., 2013, 21(3):561-565.(in Chinese) http://www.cqvip.com/QK/92835A/201303/45245243.html [12] 刘韬, 胡玥, 董健, 等.激光主动照明光学系统设计[J].中国光学, 2016(3):342-348. http://www.chineseoptics.net.cn/CN/abstract/abstract9429.shtmlLIU T, HU Y, DONG J, et al.. Design of laser active illumination optical system[J]. Chinese Optics, 2016(3):342-348.(in Chinese) http://www.chineseoptics.net.cn/CN/abstract/abstract9429.shtml [13] 李艳杰, 金光, 张元, 等.成像与激光发射系统的共口径设计与实验[J].中国光学, 2015(2):220-226. http://www.chineseoptics.net.cn/CN/abstract/abstract9252.shtmlLI Y J, JIN G, ZHANG Y, et al.. Co-aperture optical system for imaging and laser transmitting[J]. Chinese Optics, 2015(2):220-226.(in Chinese) http://www.chineseoptics.net.cn/CN/abstract/abstract9252.shtml [14] 虞林瑶, 魏群, 张天翼, 等.中波红外长焦距折返光学系统设计[J].中国光学, 2015(2):234-240. http://www.chineseoptics.net.cn/CN/abstract/abstract9251.shtmlYU L Y, WEI Q, ZHANG T Y, et al.. Design of long focal infrared catadioptric optical system for multi-guided system[J]. Chinese Optics, 2015(2):234-240.(in Chinese) http://www.chineseoptics.net.cn/CN/abstract/abstract9251.shtml [15] 李正东.激光在大气传输中的损耗和折射[J].红外与激光工程, 2003, 01:73-77. doi: 10.3969/j.issn.1007-2276.2003.01.017LI ZH D. Loss and refraction of laser transmitting in the atmosphere[J]. Infrared and Laser Engineering, 2003, 01:73-77.(in Chinese) doi: 10.3969/j.issn.1007-2276.2003.01.017 [16] 陈夫林, 张景旭, 吴小霞, 等.620 mm薄镜面的主动支撑结构及面形校正[J].光学 精密工程, 2011, 19(5):1023-1028. http://mall.cnki.net/magazine/Article/GXJM201105011.htmCHEN F L, ZHANG J X, WU X X, et al.. Supporting structure of 620 mm thin primary mirror and its active surface correction[J]. Opt. Precision Eng., 2011, 19(5):1023-1028.(in Chinese) http://mall.cnki.net/magazine/Article/GXJM201105011.htm -
