特定折射率材料及光学薄膜制备

申振峰

doi:10.3788/CO.20130606.900

特定折射率材料及光学薄膜制备

doi: 10.3788/CO.20130606.900

申振峰^,

中国科学院长春光学精密机械与物理研究所中国科学院光学系统先进制造技术重点实验室, 吉林长春 130033

基金项目:

科技部国际合作资助项目（No. 2010DFR10720）

详细信息

作者简介:
申振峰（1977-），男，吉林省吉林市人，博士，副研究员，2000年于东北师范大学获得学士学位，2009年于中国科学院长春光学精密机械与物理研究所获得博士学位，主要从事光学薄膜理论和制备以及SiC表面改性方面的研究。E-mail：zf_shen@163.com.cn

通讯作者:
申振峰

中图分类号: O484.1
计量
- 文章访问数: 2746
- HTML全文浏览量: 626
- PDF下载量: 841
- 被引次数: 0
出版历程
- 收稿日期: 2013-09-13
- 修回日期: 2013-11-16
- 刊出日期: 2013-12-10

Preparation of specific refractive index material and optical thin films

SHEN Zhen-feng^,

Key Laboratory of Optical System Advanced Manufacturing Technology, Changchun Institute of Optics, Fine Mechanics and Physics, Chinese Academy of Sciences, Changchun 130033, China

摘要

摘要: 根据太阳电池阵激光防护膜性能优化的需要，应用离子辅助电子束双源共蒸工艺方法制备了优化设计所需的特定折射率的薄膜材料并用于制备激光防护膜。测试结果显示：用该工艺方法制备的掺杂材料薄膜的折射率n=1.75，与优化设计所需数值相符；激光防护膜性能优良，太阳辐射能透过率提高6%以上，实现了对该激光防护膜性能的进一步优化。为了使该双源共蒸方法适于大面积薄膜的制备，应用均匀性挡板技术来提高该方法制备大面积薄膜的膜厚均匀性，使制备的掺杂材料薄膜在口径为400 mm时的不均匀性小于2.1%。该双源共蒸方法制备工艺简单、可靠，适于实际工程应用。薄膜性能测试结果与理论优化结果相符，达到预期优化目标。
- 薄膜材料 /
- 激光防护膜 /
- 折射率 /
- 掺杂 /
- 双源共蒸
Abstract: A material with specific refractive index is prepared according to the requirement for the preparation of the laser protective coating for solar arrays. In this method, we apply the electron beam co-evaporation technique based on doped material preparation methods. Tests show that the refractive index of the doped material is 1.75, according with the result of optimized scheme. The material is then used in the preparation of optical thin films to achieve a further optimization of the laser protective coating properties. Obtained laser protective coating has excellent properties and its solar radiation transmittance is increased by more than 6%. The film thickness mask technology is applied to improve the film thickness uniformity of large area thin films prepared by co-evaporation method. The thickness nonuniformity of doped material film prepared by this method within 400 mm area is less than 2.1%. It is showed that the technical process of electron beam co-evaporation technique is simple, reliable and suitable for practical applications. Test results of the film performance are consistent with the theoretical optimized results.
- thin film material /
- laser protective coating /
- refractive index /
- doping /
- co-evaporation

HTML全文

参考文献(1)

[1] 麦克劳德.光学薄膜技术 [M].北京:国防工业出版社,1974. MACLEOD H A. Thin-film Optical Filters[M]. Beijing:National Defense Industry Press,1974.(in Chinese) [2] 唐晋发,顾培夫,刘旭,等.现代光学薄膜技术[M]. 杭州:浙江大学出版社,2006. TANG J F,GU P F,LIU X,et al.. Modern Optical Thin Film Technology[M]. Hangzhou:Zhejiang University Press,2006.(in Chinese) [3] 孙芳芳,贺蕴秋,李一鸣,等. 透明导电ZnO薄膜的电化学制备及性能研究[J]. 发光学报,2013,34(2):218-224. Sun F F,He Y Q,LI Y M,et al.. Transparent conductive properties of ZnO thin films prepared by electrochemical deposition[J]. Chinese J. Luminescence,2013,34(2):218-224.(in Chinese) [4] 刘邦武,钟思华,何静,等. 液相沉积法制备的二氧化硅薄膜及其钝化性能[J]. 发光学报,2012,33(11):1264-1267. LIU B W,ZHONG S H,HE J,et al.. SiO₂ film synthesized by liquid phase deposition and its passivation performance[J]. Chinese J. Luminescence,2012,33(11):1264-1267.(in Chinese) [5] DONG Y,WANG P,NIE L F,et al.. Sol-gel preparation and up-conversion luminescence properties of Er³⁺, Yb³⁺ co-doped TiO₂ films[J]. Chinese J. Luminescence,2012,33(2):1006-1011. [6] WANG X J,SONG H,LI D B,et al.. Deposition of AlN films on nitrided sapphire substrates by reactive DC magnetron sputtering[J]. Chinese J. Luminescence,2012,33(2):227-232. [7] TESFAMICHAEL T,MOTTA N,BOSTROM T,et al.. Development of porous metal oxide thin films by co-evaporation[J]. Appl. Surface Sci.,2007,253:4853-4859. [8] BARTHELEMY E,ALBERT S,VIGREUX C,et al.. Effect of composition on the properties of Te-Ge thick films deposited by co-thermal evaporation[J]. J. Non-Crystalline Solids,2010,356:2175-2180. [9] TSAI R Y, HUA M Y. Microstructural, optical, and mechanical properties of reactive electron-beam-coevaporated TiO₂-MgF₂ composite films[J]. Appl. Opt.,1996,35(25):5073-5079. [10] NIKLASSON G A,CRAIGHEAD H G. Optical properties of codeposited aluminum-silicon composite films[J]. Appl. Opt.,1983,22(8):1237-1240. [11] 宫大为,付秀华,耿似玉,等. 红外双波段激光滤光膜的研制[J]. 中国光学, 2011,4(3):293-298. GONG D W,FU X H,GENG S Y,et al.. Design and manufacture of infrared double waveband laser filter films[J]. Chinese Optics,2011,4(3):293-298.(in Chinese) [12] 贾洁,郑华,耿涛,等. PHEMT 欧姆接触的双源共蒸技术[J]. 电子与封装,2007,7(11):35-38. JIA J,ZHENG H,GENG T,et al.. The co-evaporation technology of ohmic contact in GaAs PHEMT[J]. Electronics Packaging,2007,7(11):35-38.(in Chinese) [13] 沈自才,王英剑,范正修,等. 线性共蒸法制备渐变折射率薄膜的光学特性分析[J]. 中国激光,2005,32(6):829-834. SHEN Z C,WANG Y J,FAN ZH X,et al.. Analysis of optical characteristics of gradient refractive index coatings prepared by linear co-evaporation[J]. Chinese J. Lasers,2005,32(6):829-834.(in Chinese) [14] 张立超,高劲松. 长春光机所深紫外光学薄膜技术研究进展[J]. 光学精密工程,2012,20(11):2395-2401. ZHANG L CH,GAO J S. Developments of DUV coating technologies in CIOMP[J]. Opt. Precision Eng.,2012,20(11):2395-2401.(in Chinese) [15] 赵妙,周代兵,谭满清,等. 双源电子束蒸发制备Si/SiO₂光学薄膜的工艺[J]. 半导体学报,2006,27(9):1586-1589. ZHAO M,ZHOU D B,TAN M Q,et al.. Preparation of Si/SiO₂ optical thin film by double source electron beam evaporation technology[J]. Chinese J. Semiconductors,2006,27(9):1586-1589.(in Chinese) [16] 宁晓阳,杭凌侠,郭峰,等. SiO₂/TiO₂变折射率光学薄膜制造技术研究[J]. 表面技术,2011,40(6):58-61. NIN X Y,HANG L X,GUO F,et al.. Research the deposition of SiO₂/TiO₂ nonlinear refractive-index optical thin films[J]. Surface Technology,2011,40(6):58-61.(in Chinese) [17] 卫耀伟,刘志超,陈松林. TiO₂/Al₂O₃薄膜的原子层沉积和光学性能分析[J]. 中国光学,2011,4(2):188-195. WEI Y W,LIU ZH CH,CHEN S L. Optical characteristics of TiO₂/Al₂O₃ thin films and their atomic layer depositions[J]. Chinese Optics,2011,4(2):188-195.(in Chinese)
