A study of high-precision spherical wave calibration method for shack-hartmann wavefront sensor
-
摘要:
为解决哈特曼-夏克波前传感器传统标定方法存在的测量精度低、稳定性不足等问题，提出了一种基于球面波的哈特曼-夏克波前传感器高精度绝对标定的方法。通过理论推导获取了球面波的高精度标定方法，结合搭建的球面波标定实验装置，对子孔径数为128×128的哈特曼-夏克波前传感器完成高精度标定，该方法计算得到哈特曼-夏克波前传感器结构参数f，w以及L0的精确值；对标定后哈特曼-夏克波前传感器的测量精度进行测试。实验结果表明，经本文方法标定后的哈特曼-夏克波前传感器的波前复原精度达到了PV=1.376×10−2λ，RMS=4×10−3λ（λ=625 nm），重复性精度为PV=3.2×10−3λ，RMS=9.76×10−4λ（λ=625 nm）。该方法可以为大口径的SHWFS完成高精度标定，提升测量精度。
-
关键词:
- 哈特曼-夏克波前传感器 /
- 绝对标定 /
- 球面波前
Abstract:To address the issues of inaccurate measurements and unstable calibration processes in conventional Shack-Hartmann wavefront sensors (SHWFS), we propose a high-precision absolute calibration method using spherical waves generated by the sensor. The SHWFS experiences an extremely precise calibration process with 128×128 sub-apertures. This is achieved using a method of spherical wave obtained through theoretical derivation in conjunction with the constructed experimental device for spherical wave calibration. The structural parameters of the SHWFS (
f ,w , andL 0) are calculated precisely. Also, the measurement accuracy of the SHWFS is verified following calibration. The experimental results demonstrate that by using this method to calibrate the Shack-Hartmann wavefront sensor, its wavefront recovery accuracy reaches a PV of 1.376×10−2λ and an RMS of 4×10−3λ (where λ=625 nm), respectively. Additionally, its repeatability accuracy reaches a PV of 3.2×10−3λ and an RMS of 9.76×10−4λ (where λ=625 nm), respectively. These findings suggest that this method is suitable for enhancing the measurement accuracy of high-precision calibration of SHWFS with large aperture. -
图 2 球面波前在SHWFS探测器上形成的光斑图
Figure 2. Spots pattern of a spherical wavefront on the plane of the SHWFS detector
图 3 高精度球面波标定装置原理图
Figure 3. Schematic diagram of the high-precision spherical wavefront calibration device
图 4 高精度球面波标定实物装置
Figure 4. Setup of the high-precision spherical wavefront calibration
图 5 不同曲率半径的球面波前复原误差
Figure 5. Residual errors for spherical waves with different curvature radii
表 1 待标定的SHWFS的物理参数
Table 1. Parameters of the SHWFS to be calibrated
CCD相机 参数 微透镜阵列 参数 生产商 HIKROBOT 子孔径大小 0.1 mm×0.1 mm 型号 MV-CH250-90TM-M58S-NF 使用子孔径数 128×128 像素个数 5120×5120 焦距 2.4 mm 像素尺寸 2.5 um x 2.5 um 通光口径 Φ12.8 mm
下载: 导出CSV
表 2 待标定的SHWFS的参数测量值
Table 2. Measured values for parameters of the SHWFS to be calibrated.
实验结果
参数f/mm $ \mathrm{w}=\dfrac{\mathrm{P}}{\mathrm{S}} $ L0/mm 测量次数 1 2.402 39.960 1050.00 2 2.402 39.960 1050.00 3 2.402 39.960 1050.00 4 2.403 39.959 1050.00 5 2.402 39.960 1050.00 6 2.402 39.960 1050.00 7 2.403 39.959 1050.00 8 2.402 39.960 1050.00 9 2.401 39.961 1050.00 10 2.402 39.960 1050.00 均值 2.402 39.960 1050.00
下载: 导出CSV
-
[1] TYSON R K, FRAZIER B W. Principles of Adaptive Optics[M]. 5th ed. Boca Raton: CRC Press, 2022. [2] WEI K, LI M, CHEN SH Q, et al. First light for the sodium laser guide star adaptive optics system on the Lijiang 1.8m telescope[J]. Research in Astronomy and Astrophysics, 2016, 16(12): 183. doi: 10.1088/1674-4527/16/12/183 [3] SCHÄFER B, LÜBBECKE M, MANN K. Hartmann-Shack wave front measurements for real time determination of laser beam propagation parameters[J]. Review of Scientific Instruments, 2006, 77(5): 053103. doi: 10.1063/1.2198795 [4] SAKHAROV A M, BARYSHNIKOV N V, KARASIK V E, et al. A method for reconstructing the equation of the aspherical surface of mirrors in an explicit form using a device with a wavefront sensor[J]. Proceedings of SPIE, 2020, 11487: 114870B. [5] HE Y, DENG G H, WEI L, et al. Design of a compact, bimorph deformable mirror-based adaptive optics scanning laser ophthalmoscope[M]//LUO Q M, LI L Z, HARRISON D K, et al. Oxygen Transport to Tissue XXXVIII. Cham: Springer, 2016: 375-383. [6] 朱沁雨, 韩国庆, 彭建涛, 等. 双波长视网膜成像自适应光学系统的轴向色差补偿方法[J]. 中国光学,2022,15(1):79-89. doi: 10.37188/CO.EN.2021-0009ZHU Q Y, HAN G Q, PENG J T, et al. Longitudinal chromatic aberration compensation method for dual-wavelength retinal imaging adaptive optics systems[J]. Chinese Optics, 2022, 15(1): 79-89. (in Chinese). doi: 10.37188/CO.EN.2021-0009 [7] 王艳萍, 王茜蒨, 马冲. 哈特曼波前分析仪校准方法研究[J]. 中国激光,2015,42(1):0108003. doi: 10.3788/CJL201542.0108003WANG Y P, WANG Q Q, MA CH. Study on Hartmann wavefront analyzer calibration method[J]. Chinese Journal of Lasers, 2015, 42(1): 0108003. (in Chinese). doi: 10.3788/CJL201542.0108003 [8] ARTZNER G. On the absolute calibration of Shack-Hartmann sensors and UV laboratory wavefront measurements[J]. Pure and Applied Optics:Journal of the European Optical Society Part A, 1994, 3(2): 121-132. doi: 10.1088/0963-9659/3/2/005 [9] GREIVENKAMP J E, SMITH D G, GOODWIN E. Calibration issues with Shack-Hartmann sensors for metrology applications[J]. Proceedings of SPIE, 2004, 5252: 372-380. doi: 10.1117/12.513462 [10] CHERNYSHOV A, STERR U, RIEHLE F, et al. Calibration of a Shack–Hartmann sensor for absolute measurements of wavefronts[J]. Applied Optics, 2005, 44(30): 6419-6425. doi: 10.1364/AO.44.006419 [11] NIKITIN A N, GALAKTIONOV I, SHELDAKOVA J, et al. Absolute calibration of a Shack-Hartmann wavefront sensor for measurements of wavefronts[J]. Proceedings of SPIE, 2019, 10925: 109250K. [12] BAUTSCH J, SCHAKE M, EHRET G, et al. Traceable calibration of Shack–Hartmann wavefront sensors employing spherical wavefronts[J]. Optical Engineering, 2020, 59(8): 084104. [13] YANG J SH, WEI L, CHEN H L, et al. Absolute calibration of Hartmann-Shack wavefront sensor by spherical wavefronts[J]. Optics Communications, 2010, 283(6): 910-916. doi: 10.1016/j.optcom.2009.11.022 [14] 梁春, 沈建新, 童桂, 等. Hartmann-Shack传感器结构参量的自基准标定[J]. 光子学报,2009,38(4):780-784.LIANG CH, SHEN J X, TONG G, et al. A self-reference method for measuring Hartmann-shack wavefront sensor parameter[J]. Acta Photonica Sinica, 2009, 38(4): 780-784. (in Chinese). [15] 周晓斌, 栾亚东, 史雷蕾, 等. 基于已知球面波前的Hartmann-Shack传感器结构参量标定[J]. 应用光学,2015,36(6):909-912. doi: 10.5768/JAO201536.0603002ZHOU X B, LUAN Y D, SHI L L, et al. Structural parameters calibration of Hartmann-Shack sensor based on known spherical wavefront[J]. Journal of Applied Optics, 2015, 36(6): 909-912. (in Chinese). doi: 10.5768/JAO201536.0603002 [16] NIKITIN A N, GALAKTIONOV I, SHELDAKOVA J, et al. Calibration of a Shack-Hartmann wavefront sensor using spherical wavefronts from a point source[J]. Proceedings of SPIE, 2022, 11987: 119870J. [17] PLATT B C, SHACK R. History and principles of Shack-Hartmann wavefront sensing[J]. Journal of Refractive Surgery, 2001, 17(5): S573-S577. [18] BORN M, WOLF E. Principles of Optics: Electromagnetic Theory of Propagation, Interference and Diffraction of Light[M]. 7th ed. Cambridge: Cambridge University Press, 1999. (查阅网上资料, 未找到本条文献2013年版本信息, 请确认) .BORN M, WOLF E. Principles of Optics: Electromagnetic Theory of Propagation, Interference and Diffraction of Light[M]. 7th ed. Cambridge: Cambridge University Press, 1999. (查阅网上资料, 未找到本条文献2013年版本信息, 请确认). -
